          14. BATTERY/CHARGING SYSTEM/
     A.C. GENERATOR                                                                         PEOPLE 125/150


14




     BATTERY/CHARGING SYSTEM/A.C. GENERATOR


     CHARGING SYSTEM LAYOUT ..................................................... 14-1
     SERVICE INFORMATION ............................................................... 14-2
     TROUBLESHOOTING ...................................................................... 14-3
     BATTERY ............................................................................................ 14-4
     CHARGING SYSTEM........................................................................ 14-5
     REGULATOR/RECTIFIER .............................................................. 14-6
     A.C. GENERATOR CHARGING COIL............................................ 14-7
     A.C. GENERATOR LIGHTING COIL ............................................. 14-7
     RESISTOR INSPECTION ................................................................. 14-7
     A.C. GENERATOR ............................................................................. 14-7
