          10. FINAL REDUCTION                                                           PEOPLE 125/150
 BEARING REPLACEMENT (LEFT
 CRANKCASE)
 Remove the drive shaft.
 Remove the drive shaft oil seal.
 Remove the left crankcase bearings using a
 bearing remover.




                                                                              Pilot

 Drive new bearings into the left crankcase.
 Install a new drive shaft oil seal.




 FINAL REDUCTION ASSEMBLY
 Install the drive shaft into the left crankcase.
 Inspect the drive shaft and gear for wear or
 damage.




                                                                           Drive Shaft
                                                                        Final Gear

 Install the final gear and final shaft into the
 left crankcase.
 Install the countershaft and gear into the left
 crankcase.
 Install the washer onto the countershaft.
 Install the dowel pins and a new gasket.




                                                         Countershaft                 Drive Shaft

                Bearing Remover, 17mm               Install the transmission case cover.

10-5
