          13. REAR WHEEL/REAR BRAKE/
    REAR SUSPENSION                                               PEOPLE 125/150
 Remove the rear shock absorber upper and           Bolt
 lower mount bolts.
 Remove the rear shock absorber.




                                                                       Bolt
                                                     Adjust Position
 ADJUSTABLE REAR CUSHION
 To suit scooter behaviour to load condition
 rear cushion could be adjusted in spring
 prelocad.
 It is possible to adjust rear cushion in three
 positions:
 A position "soft"
 B position "medium"
 C position "hard"
 When you adjust rear cushion, the spring
 preload of rear cushions must be the same.



 INSTALLATION
 Install the rear shock absorber. First install
 the upper mount bolt and then the lower
 mount bolts and tighten them.
 Install the air cleaner case and tighten the two
 bolts.
 Install the frame body cover.
 Torque:
 Upper Mount Bolt: 4.0kg-m
 Lower Mount Bolt: 2.5kg-m




                                                                              13-6
