12. COOLING SYSTEM Downtown 125 i
(2)
RADIATOR
REMOVAL
Drain the coolant.
Disconnect the siphon hose (1) and air
bleed hose (2).
Remove the nut(3).
(3) (1)
(5)
Loosen the hose bands, then disconnect the
input radiator hose (4) and output radiator
hose (5) from the radiator.
Disconnect the thermal switch connectors
(6).
(6) (4)
. Disconnect the fan motor connector (7)
.
(7)
12-7
