          20. LIGHTS/METERS/SWITCHES                       DOWNTOWN 125i

 INSPECTION

 Connect the fuel unit wire connectors and                   F
 turn the ignition switch "ON".
 Before performing the following test,
    operate the turn signals to determine that
    the battery circuit is normal.




                                                             E




 Measure the resistance between the
 Yellow/White and Blue/White terminals of
 the fuel unit connector.

 Standard (at 20°C/68°F):
 Float at full position  About1100
 Float at empty position About100




20-11
