          1. GENERAL INFORMATION                                    DOWNTOWN 125i

  Route harnesses so they are neither pulled
  tight nor have excessive slack.                                Do not pull
                                                                 too tight!




  Protect wires and harnesses with electrical
  tape or tube if they contact a sharp edge or
  corner.




  When rubber protecting cover is used to
  protect the wire harnesses, it shall be
  installed securely.




  Do not break the sheath of wire.
  If a wire or harness is with a broken sheath,
  repair by wrapping it with protective tape
  or replace it.
                                                  Do not press or
                                                  squeeze the wire.




  When installing other parts, do not press
  or squeeze the wires.




                                                                               -8-
