          1. GENERAL INFORMATION                                                          DOWNTOWN 125i

      After routing, check that the wire harnesses
      are not twisted or kinked.




      Wire harnesses routed along with handlebar
      should not be pulled tight, have excessive
      slack or interfere with adjacent or surrounding
      parts in all steering positions.




                                                        Do you understand the
                                                        instrument?
                                                        Is the instrument
                                                        set correctly?

      When a testing device is used, make sure to
      understand the operating methods
      thoroughly and operate according
      to the operating instructions.




                                                                        Remove Rust !
      Be careful not to drop any parts.




      When rust is found on a terminal, remove
      the rust with sand paper or equivalent before
      connecting.
