          1. GENERAL INFORMATION                                               DOWNTOWN 125i

    SPECIAL TOOLS


                                                                         Illustration
                                                          (Note: the special tools may differ
                     Tool Name                Tool No.
                                                                 slightly from those shown in the
                                                                 figure of this manual.)


         Bearing puller                      A120E00037


         Valve spring compressor

         (Refer to the "CYLINDER             A120E00040
         HEAD" section in the chapter 6.)


         Lock nut wrench

         (Refer to the "STEERING             A120F00023
         STEM" section in the chapter 15.)


         Lock nut wrench

         (Refer to the "STEERING             A120F00002
         STEM" section in the chapter 15.)


         Bottom Ball Race
         Remove special tool/ Top Ball
         Cone Race Remove special tool
                                             A120F00009

         (Refer to the "STEERING
         STEM" section in the chapter 15.)




         Bottom Ball Race
         Install special tool
         Top Ball Cone Race
                                             A120F00019
         Install special tool
         (Refer to the "STEERING
         STEM" section in the chapter 15.)



- 13 -
                                                                                            1-13
