          6. CYLINDER HEAD/VALVES                                    DOWNTOWN 125i



 INSPECTION


 Camshaft

 Inspect camshaft lobes for
 pitting/scratches/blue discoloration.




 If any defects are found, replace the camshaft
 with a new one, then inspect lubrication         Camshaft Bearings
 system.

 Check each camshaft bearing for play or
 damage. Replace the camshaft assembly with
 a new one if the bearings are noisy or have
 excessive play.




6-9
