9. FINAL REDUCTION DOWNTOWN 125 i
SERVICE INFORMATION
GENERAL INSTRUCTIONS
· The servicing operations of this section can be made with the engine installed.
· When replacing the drive shaft, use a special tool to hold the bearing inner race for this operation.
SPECIFICATIONS
Specified Oil: SAE 90#
Oil Capacity:
At disassembly : 0.13L
At change : 0.12L
TORQUE VALUES
Transmission case cover bolt 1.0~1.4kgf-m
SPECIAL TOOLS
Oil seal and bearing installer A120E00014
Bearing puller A120E00037
TROUBLESHOOTING
Engine starts but motorcycle fail to move
· Damaged transmission
· Seized or burnt transmission
Abnormal noise
· Worn, seized or chipped gears
· Worn bearing
Oil leaks
· Oil level too high
· Worn or damaged oil seal
9-2
