          12. COOLING SYSTEM                                         Downtown 125 i


 Remove the screw (3) and reserve tank lid
 (4).




                                                 (4)


                                                                (3)




 Remove the reserve tank cap (5) and drain
 the coolant from the reserve tank.

 Reinstall and tighten the drain bolt
 securely.
                                                                 (5)




 Fill the reserve tank to the upper level line
 (6).
                                                       F
                                                       L




12-5
