          1. GENERAL INFORMATION                                                         PEOPLE 125/150

 LUBRICATION POINTS

 ENGINE
 Lubrication Points                                 Lubricant
  Valve guide/valve stem movable part                ·Genuine KYMCO Engine Oil (SAE15W-40)
  Cam lobes                                          ·API SE, SF or SG Engine Oil
  Valve rocker arm friction surface
  Cam chain
  Cylinder lock bolt and nut
  Piston surroundings and piston ring grooves
  Piston pin surroundings
  Cylinder inside wall
  Connecting rod/piston pin hole
  Connecting rod big end
  Crankshaft right side oil seal
  Crankshaft one-way clutch movable part
  Oil pump drive chain
  Starter reduction gear engaging part
  Countershaft gear engaging part
  Final gear engaging part
  Bearing movable part
  O-ring face
  Oil seal lip
  Starter idle gear
  Friction spring movable part/shaft movable part    High-temperature resistant grease
  Shaft movable grooved part
  Starter spindle movable part
  Starter one-way clutch threads                     Thread locking agent
  A.C. generator connector                           Adhesive
  Transmission case breather tube




                                                                                         1-9
