          5. ENGINE REMOVAL/INSTALLATION               DOWNTOWN 125i


 Remove the engine mount nut
 Pull out the engine mount bolt.




 Remove the engine from the frame.




 At removing the engine, be careful not to
   catch your hand or finger between the
   engine hanger and crankcase.




                                                     5-6
