20. LIGHTS/METERS/SWITCHES DOWNTOWN 125i
(2)
HEADLIGHT (1)
A halogen headlight bulb becomes very
hot while the headlight is ON, and
remain for a while after it is turned OFF.
Be sure to let it cool down before
servicing.
Remove the front cover (refer to the
"FRAME COVERS
REMOVAL/INSTALLATION" section in
the chapter 2).
Disconnect the headlight cover
Disconnect the headlight connector (1) from
the headlight bulb (2).
Install a new bulb in the headlight case,
Install the headlight and connect the headlight
connector
20-3
