 FLOAT LEVEL INSPECTION
 Measure the float level at the location of the
 main jet (just contacting the float valve).
 Float Level: 18.51.0mm
 Replace the float if the level is incorrect.
 Check the operation of the float and then
 reinstall the float chamber.




                                                                    Float



                                                                    Vacuum Piston
 VACUUM CHAMBER ASSEMBLY
 First install the jet needle and spring into the
 vacuum chamber and then install the needle
 holder.




                                                    Needle Holder             Jet Needle


                                                                            Vacuum Piston
 Install the vacuum piston into the carburetor
 body.
 Install the spring.
 Install the vacuum chamber cover and tighten
 it with the two screws.

 · Be careful not to let the diaphragm
      slip.
    · If the diaphragm cannot be positioned
      correctly because of expansion, dry the
      di h        b f   i t ll ti


                                                        Spring                    Diaphragm
