9. DRIVE AND DRIVEN PULLEYS/ KICK STARTER PEOPLE 125/150 Clutch Spring Compressor Hold the clutch/driven pulley assembly with the clutch spring compressor. Be sure to use a clutch spring compressor to avoid spring damage. Special Clutch Spring Compressor Set the clutch spring compressor in a vise and remove the clutch drive plate nut. Lock Nut Wrench Special Lock Nut Wrench, 39mm Loosen the clutch spring compressor and disassemble the clutch/driven pulley assembly. Remove the seal collar. Check the driven face for wear or damage. Measure the clutch lining thickness. Service Limit: 33.94mm replace if below Pull out the guide roller pins and guide rollers. O-ring Guide Roller Pin Remove the movable driven face from the driven face. Movable Driven F 9-8
