          13. FUEL SYSTEM/CARBURETOR/
     FUEL PUMP/ FUEL TANK                                         DINK 50/125



 CARBURETOR HEATER                                  Connectors   Heater


 INSPECTION/REPLACEMNER

 Check the heater with battery.
 If the heater is getting hot, means the heater
 without problem, otherwise the heater has to
 be changed.

 Remove the carburetor (refer to the
 "CARBURETOR" section in this chapter).

 Remove the screw.
 Disconnect the connectors form the heater.

 It is in reverse order of removal to install the
 new heater.




13-21
