          13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK                           DINK 50/125


 Remove the carburetor.

 Disconnect the fuel hose from the
 carburetor.

 Installation is in the reverse order of
 removal.
Adjust the throttle grip free play (refer to
   the "THROTTLE OPERATION"
   section in the chapter 3) after the
   carburetor has reinstalled.




                                                   13-8
