8. DRIVE AND DRIVEN PULLEYS/
KICK STARTER DINK 50/125
Check the clutch shoes for wear or damage.
Measure the clutch lining thickness. Inner Bearing
Service Limit: 2.0mm replace if below
Measure the driven face spring free length.
Service Limit: 82.6mm replace if below
Outer Bearing
Check the driven face assembly for wear or
damage.
Measure the driven face O.D.
Service Limit: 33.94mm replace if below
Check the movable driven face for wear or
damage.
Measure the movable driven face I.D.
Service Limit: 34.06mm replace if below
Check the guide roller pins for stepped wear.
Bearing Outer Driver
8-33
