                                                            AF983                                                      AF993




                                                  AF984                                                      AF994
                                                           2. Install the input shaft seal making sure it is flush
                                                              with the edge of the housing.
                                                           3. Lubricate the input shaft splines with High-Perfor-
                                                              mance #2 Molybdenum Disulphide Grease.
                                                            NOTE: Any time drive splines are separated,
                                                          clean all splines with parts-cleaning solvent and
                                                          dry with compressed air; then lubricate with rec-
                                                          ommended grease.



                                                  KX219


Assembling Input Shaft

 1. Place the pinion housing in a press and install the
    input shaft bearing. Secure the bearing with the
    existing snap ring making sure the sharp edge of
    the snap ring faces to the outside.


                                                                                                            KX221




6-6
