6. CYLINDER HEAD/VALVES People GT 125i
Measure the I.D. of each valve rocker arm.
Service Limits:
IN: 10.1 mm
EX: 10.1 mm
Measure each rocker arm shaft O.D.
Service Limits:
IN: 9.9 mm
EX: 9.9 mm
Measure arm to shaft clearance.
Replace as a set if out of specification.
Service limits: 0.1 mm
ASSEMBLY
Rocker Arm Shafts
Apply engine oil to the rocker arms and
rocker arm shafts.
Install the rocker arms and shafts into the
camshaft holder.
· Install the exhaust valve rocker arm
shaft on the "EX" side of the camshaft
holder and the exhaust rocker arm shaft
is shorter.
· Clean the intake valve rocker arm shaft
off any grease before installation.
· Align the cutout on the exhaust valve
rocker arm shaft with the bolt of the
camshaft holder.
6-7
