          3. INSPECTION/ADJUSTMENT                                               People GT 125i



 AIR CLEANER
 AIR FILTER REPLACEMENT
 Remove the body cover.
 Remove seven screws attaching to the air
 cleaner cover.
 Remove six screws attaching to the filter.
 Check the filter and replace it if it is
 excessively dirty or damaged.

                                                Air Cleaner Cover

 CHANGE INTERVAL
 More frequent replacement is required when
 riding in unusually dusty or rainy areas.
  · The air cleaner element has a viscous
       type paper element. Do not clean it
       with compressed air.
     · Be sure to install the air cleaner
       element and cover securely.




 SPARK PLUG
 Remove the spark plug cap and spark plug.
 Check the spark plug for wear and fouling
 deposits.
 Clean any fouling deposits with a spark plug
 cleaner or a wire brush.

 Specified Spark Plug: NGK-CR7E
 Measure the spark plug gap.
 Spark Plug Gap: 0.6 ­ 0.7 mm



                                                         Spark Plug
 · When installing, first screw in the spark
     plug by hand and then tighten it with a
     spark plug wrench.

                                                                      Cracks
                                                                      Damage
 Torque:17.2 N-m
                                                   Gap                  Deformation
                                                   Wear

                                                   Fouling
                                                   Deposits
                                                                      0.6~0.7 mm




                                                                                   3-6
