          17. IGNITION SYSTEM                                 People GT 125i




 REMOVAL/INSTALLATION
 Disconnect the connector and remove two
 screws, then remove tilt switch.
 Installation is in the reverse order of removal.


    Install the tilt switch with its "up" mark
    facing up.


 Tighten the mounting screws securely.




17-5
