          14. STEERING HANDLEBAR/FRONT WHEEL/FRONT
    BRAKE/FRONT SHOCK ABSORBER/FRONT FORK                          People GT 125i


                                                    Washers   Brake Fluid Tube
  BRAKE CALIPER
  REMOVAL
  First drain the brake fluid from the hydraulic
  brake system.
  Remove the brake fluid tube bolt.
  Remove the two bolts attaching the brake
  caliper.
  Remove the brake caliper.




                                                                        Bolts

  INSTALLATION
  Install the two brake pads.
  Install the two brake pad dowel pin and
  tighten them.
  When      installing the brake caliper, be
     sure to position the brake disk between
     the two brake pads.


  Install the brake caliper to the shock absorber
  and tighten the two bolts.
  Torque: 35 N-m
  Connect the brake fluid tube with the
  attaching bolt and two sealing washers to the
  brake caliper and tighten the fluid tube bolt.
  Torque: 35 N-m
  Fill the brake reservoir with the specified
  brake fluid and bleed air from the brake
  system. ( 14-10)
  When installing the brake fluid tube, be
     sure to install the two sealing washers.




14-11
