                                                        KC219A                                                     KC260
3. Remove the gas tank cap; then remove the gas
   tank cover. Place gas tank cap back on tank.




                                                                                                         KC262
                                                                                                                 4
                                                        CLEANING AND INSPECTING
                                                KC220
4. Remove the gas tank valve knob.                       NOTE: Whenever a part is worn excessively,
                                                        cracked, or damaged in any way, replacement is
5. Remove the cap screw securing the gas tank to the    necessary.
   frame and using a suitable block, support the rear
   of the tank; then remove the clamp securing the
   gasline hose and remove the hose from the gas        1. Clean all gas tank components with parts-cleaning
   tank valve.                                             solvent.
                                                        2. Inspect all hoses for cracks or leaks.
                                                        3. Inspect tank cap and tank for leaks, holes, and
                                                           damaged threads.
                                                        INSTALLING

                                                        1. Using a block to hold the front body open, place
                                                           the gas tank into position in the frame making sure
                                                           the heat shield is in position.



                                              KC241A
6. Using a suitable block, hold the front body open
   and remove the gas tank to the rear. Account for
   the heat shield.




                                                                                                         KC262




                                                                                                          4-9
