                                                           KC252A                                                      KC219A
 2. Using a suitable block, support the rear of the tank    5. Install the side panels and seat making sure it locks
    and connect the gasline hose to the gas tank valve         securely in place. Turn the gas tank valve to the
    outlet. Secure with a clamp.                               ON position and check for leaks.


                                                                 Oil Filter/Oil Pump

                                                             NOTE: Whenever internal engine components
                                                           wear excessively or break and whenever oil is con-
                                                           taminated, the oil pump should be replaced. The
                                                           oil pump is not a serviceable component.




                                                 KC241A
                                                                   Testing Oil Pump
 3. Remove all blocking and secure the gas tank with                   Pressure
    the cap screw. Tighten securely.

                                                            1. Connect the Tachometer to the engine.
                                                            2. Connect the Oil Pressure Test Kit to the oil filter
                                                               drain plug.




                                                 KC225A
 4. Secure the rear of the front body to the frame with
    the cap screws (A) and tighten securely; then
    install the gas tank cover and secure with the rein-
    stallable rivets (B).
                                                                                                             KC195A




4-10
