6. Using Magneto Rotor Remover, break the rotor/flywheel assembly loose from the crankshaft. Remove the remover, the crankshaft protector, the rotor/flywheel, and the starter clutch gear. Account for the key. ! CAUTION Care must be taken that the remover is fully threaded onto the rotor/flywheel or damage may occur. MD1305 8. Remove the gear shift shaft assembly and washer from the left-side crankcase. Note the positions of the alignment marks and washer for installing pur- poses; then release the cam stopper spring tension. 3 MD1368 MD1239 9. Remove the shift detent cam. Note position of spacer for installing purposes. 10. Remove the cam stopper assembly. 11. Remove two starter motor cap screws. MD1369 KC217 MD1370 12. Remove starter motor by tapping lightly with a mallet. 7. Remove the starter idler gear (No. 1) and starter idler gear (No. 2). NOTE: The starter motor is a non-serviceable component and must be replaced as an assembly. 13. Using an impact screwdriver, remove the three Phillips-head screws holding the crankshaft bear- ing retainer. Remove the crankshaft bearing retainer. 3-27
