          1. GENERAL INFORMATION                                    People GT 125i




             01: Inductive ignition coil
             02: Fuel pump
             03: ECU
             04: Fuel injector
             05: WTS sensor
             06: T-MAP sensor
             07: ABV
             08: TPS                     02
 09          09: Roll sensor(Angle detect sensor)
             10: CPS
             11: O2/O2 HT sensor
                                                     01

                                               03   06    07   08


 10

        11




                                       04     05




                                                                1-14
