          11. CRANKCASE/CRANKSHAFT                                                          People GT 125i



 SERVICE INFORMATION
 GENERAL INSTRUCTIONS
 · This section covers crankcase separation to service the crankshaft. The engine must be removed
   for this operation.
 · When separating the crankcase, never use a driver to pry the crankcase mating surfaces apart
   forcedly to prevent damaging the mating surfaces.
 · When installing the crankcase, do not use an iron hammer to tap it.
 · The following parts must be removed before separating the crankcase.
   Cylinder head
   Cylinder/piston (chapter 7)
   Drive and driven pulley (chapter 8)
   A.C. generator/starter clutch (chapter 10)
   Rear wheel/rear shock absorber (chapter 16)
   Starter motor (chapter 19)
   Oil pump (chapter 4)


 SPECIFICATIONS
      Part                           Item                       Standard (mm)
                 Connecting rod big end side clearance             0.150.35
   Crankshaft
                 Connecting rod big end radial clearance            00.008


 TORQUE VALUES
 Crankcase bolt                          1.0 kgf-m
 Cam chain tensioner slipper bolt        1.0 kgf-m




 TROUBLESHOOTING
 Excessive engine noise
 · Excessive bearing play
 · Excessive crankpin bearing play
 · Worn piston pin and piston pin hole




                                                                                        11-2
