          6. ENGINE REMOVAL/INSTALLATION                                          AGILITY 125


 ENGINE REMOVAL
 Disconnect the battery negative cable.
 Remove the frame body cover.
 Disconnect the engine negative cable.
 Disconnect the spark plug high tension
 wire.
 Disconnect the auto bystarter wire
 connector.




                                                 Auto Bystarter Wire Connector

                                                                           Starter Relay
 Disconnect the starter motor cable from the
 starter relay.
 Remove the spark plug cap and disconnect
 the ignition coil wire from the set plate.




                                                 Vacuum Tube                     Fuel Tube
 Disconnect the fuel tube and vacuum tube
 that go to the carburetor from the fuel pump.
 Disconnect the vacuum tube from the air
 cut-off valve.
 Disconnect the throttle cable from the
 carburetor.




                                                                                      Tee Tube
                                                 Connecting Tube

 Loosen the drive belt air cleaner connecting
 tube band screw and remove the connecting
 tube.




                                                                          Screw
                                                                                             6-2
