          1. GENERAL INFORMATION                                                                                                     AGILITY 125

SPECIFICATIONS
Motorcycle Name & Type                AGILITY 125                                    Air cleaner type & No   Paper element, wet
Name & Model No.                            LDF7                                     Fuel capacity                 5 liter




                                                             Fuel System
Overall length (mm)                          1830                                           Type                    CVK




                                                                                      Carburetor
Overall width (mm)                            690                                           Piston dia. (mm)        22
Overall height (mm)                          1130                                           Venturi dia.(mm)   37equivalent
Wheel base (mm)                              1300                                           Throttle type      Butterfly type
Engine type                                 O.H.C.                                          Type                    CDI




                                                              Electrical Equipment

                                                                                      Ignition System
Displacement                               124.6cc                                          Ignition timing BTDC27°2°/4000rpm
Fuel Used                          92# nonleaded gasoline                                   Contact breaker Non-contact point type
                     Front wheel              40
Net weight (kg) Rear wheel                   65.5                                                            Spark plug    CHAMPION         P-
                         Total              105.5                                                                             RZ9 HC
                     Front wheel              40
Gross weight(kg) Rear wheel                  69.5                                          Spark plug gap                     0.60.7mm
                         Total              109.5                                    Battery Capacity                           12V7AH
                     Front wheel      120/70 -12 56J                                 Clutch Type                          Dry multi-disc clutch
                                                              Power Drive System



Tires
                                                                                      sion Gear Gear
                                                                                      Transmis- Reduction
                      Rear wheel      130/70 -12 56J                                                        Type          Non-stage transmission
Ground clearance (mm)                         127                                                           Operation     Automatic centrifugal
                                       7 (Initial speed                                                                           type
Perform- Braking distance (m)              30km/h)
ance                                                                                                        Type          Two-stage reduction
           Min. turning radius (m)           1.99
                                      Starting motor &                    Reduction 1st       0.95-2.8
      Starting system                    kick starter                     ratio      2nd        2.94
      Type                           Gasoline, 4-stroke
                                                                  Front Caster angle             27°
      Cylinder arrangement             Single cylinder
                                                              Moving Device




                                                                  Axle Trail length
      Combustion chamber type           Semi-sphere
      Valve arrangement                     O.H.C.                Tire pressure    Front        1.75
                                                                  (kg/cm)          Rear         2.25
      Bore x stroke (mm)                52.4 x 57.8
      Compression ratio                   9.60.2                  Turning          Left          45°
      Compression pressure                                        angle            Right         45°
      (kg/cm-rpm)                           132
                                                            Brake system           Front DISK (160mm) brake
      Max. output                   6.9/7500kw/(r/min)                             Rear Drum (140mm) brake
                                                            type
 Engine




      Max. torque                    9.1/6500N.m/rpm
                          Open               -2.5°                               Front                                       TELESCOPE
                                                            Device
                                                            Damping




              Intake                                                                 Suspension type
      Port                Close               32°                                Rear                                          Unit Swing
      timing              Open                -3°                 Shock absorber Front                                       410.12.5mm
              Exhaust                                             distance       Rear                                         351.62mm
                          Close                3°
      Valve clearance    Intake              0.12           Frame type                                                       Steel Pipel
      (cold) (mm)        Exhaust             0.12
      Idle speed (rpm)                 1700100rpm
              Lubrication type       Forced pressure &
          System
          Lubrication




                                          wet sump
              Oil pump type        Inner/outer rotor type
              Oil filter type       Full-flow filtration
              Oil capacity                 0.8 liter
      Cooling Type                   Forced air cooling
