6. CYLINDER HEAD/CYLINDER/PISTON SUPER8 50 2T
A Mark
The cylinder has an `A' mark or no mark
on it. When replacing the cylinder with a
new one, use a cylinder having the
same mark as the old one.
Measure the piston O.D. at a point 5mm
from the bottom of the piston skirt.
Service Limit:
38.90mm replace if below
Measure the piston-to-cylinder clearance.
Service Limit:
0.10mm replace if over
Measure the piston pin hole I.D.
Service Limit:
12.03mm replace if over
Measure the piston pin O.D.
Service Limit:
11.98mm replace if below
Measure the piston-to-piston pin clearance.
Service Limit:
0.03mm replace if over
6-8
