                                                                  SPECIAL TOOLS
   Engine/Transmission                                  A number of special tools must be available to the
                                                        technician when performing service procedures in
                                                        this section.
This section has been organized into sub-sections
which show a progression for the complete                               Description              p/n
servicing of the KYMCO ATV engine/transmission.         Clutch Sleeve Hub Holder                 E017

To service the center   crankcase     halves,    the    Connecting Rod Holder
engine/transmission must be removed from the frame.     Crankcase Separator/Crankshaft Remover   E026
To service top-side, left-side, and right-side compo-   Magneto Rotor Remover                    E073
nents, the engine/transmission does not have to be
removed from the frame.                                 Oil Filter Wrench                        E052

   NOTE: KYMCO recommends the use of new                Piston Pin Puller
gaskets, lock nuts, and seals and lubricating all
internal components when servicing the engine/          Side Case Puller
transmission.
                                                        Spanner Wrench

                                                        Surface Plate
  NOTE: Some photographs and illustrations
used in this section are used for clarity               Valve Clearance Adjuster                 E012
purposes only and are not designed to depict
actual conditions.                                      V Blocks


  NOTE: Critical torque specifications are located       NOTE: Special tools are available from the
in Section 1.                                           KYMCO Spare Parts Department.
