2. Inspect the muffler internally by shaking the muf- fler back and forth and listening for rattles or loose debris inside the muffler. NOTE: For additional details on cleaning the muf- fler/spark arrester, see Section 2. INSTALLING MUFFLER 1. Using a new grafoil seal, place the muffler into position engaging the mounting lugs into the grommets; then slide the muffler forward. 2. Install the two exhaust springs. KC322A 3. Remove the auxiliary brake reservoir from the body but do not disconnect the hose; then route Rear Body Panel/Rack and secure the hose and reservoir out of the way making sure not to spill brake fluid. REMOVING 1. Remove the rear rack; then remove two cap screws securing the rear body panel/fender to the side frame and the cap screws securing the rear fenders to the footwells. KC306 4. Using a small screwdriver, remove the light con- nectors from the frame; then disconnect both con- nectors and remove the rear body panel/fender. KC317A 8 KC281 KC316 2. Disconnect the battery (negative cable first) and remove from the battery compartment; then dis- connect the starter relay wires and route the wiring out of the compartment. 8-9
