13. Fi DIAGNOSTIC TOOL OPERATION K-XCT 125i
The figure includes fuel injector interval,
ignition advance angle andABV angle.
Refer to standard specifications .
Press the " Down " button to enter page 05.
The figure includes O2 sensor voltage, O2
heater working condition and O2 correction.
Refer to standard specifications .
Press the " Down " button to enter page 06.
The figure includes rollover voltage .
Refer to standard specifications .
Press the " Down " button to enter page 07.
The figure includes ECU counter hours.
Press the " UP " button to the first page.
13-7
