12. CARBURETOR VITALITY 50
CARBURETOR BODY CLEANING
Blow compressed air through all passages
of the carburetor body.
· Make sure that no fuel jet is clogged.
Spring Cut-off Valve Cover
Install the O-ring onto the air-cut-off valve
body securely.
· Install the O-ring with the flat face
toward the valve body side.
Install the diaphragm, spring, and cover.
O-ring Diaphragm
Screws Screws
Install and tighten the two screws attaching
the air cut-off valve cover.
Install the throttle cable holder and tighten
the two screws.
Cut-off Valve Cover Throttle Cable Holder
12-22
