10. DRIVE PULLEY/DRIVEN PULLEY/CLUTCH UXV 500 CLUTCH DISASSEMBLY/INSPECTION/ ASSEMBLY DISASSEMBLY Remove the clutch housing and clutch carrier assembly (refer to the "CLUTCH REMOVAL/INSTALLATION" section in this chapter). Remove the one-way clutch bearing from the clutch housing. One-way Clutch Bearing Oil Seal Clutch housing removal (not USA type): Remove the oil seal. Remove the snap ring, then remove the clutch housing. Snap Ring Snap Ring Remove the snap ring, then remove the bearing. Bearing 10-21
