9. CLUTCH/GEAR SHIFT MECHANISM K-PIPE 125 Lubricate the clutch rollers, springs and one- Clutch Rollers Snap Ring way clutch inner, and install them into the clutch drum. Install the one-way clutch stopper plate and secure it with the snap ring. Springs Clutch Inner Stopper Plate Clutch Holder Install the plane washer and centrifugal clutch lock nut. Install the clutch holder and secure it with two bolts. Tighten the lock nut to the specified torque. TORQUE: 3.84.5kg-m Special Clutch holder Lock nut wrench Lock Nut Wrench Install the oil filter rotor cover and a new Gasket gasket. Secure the oil filter rotor with the three bolts. Cover Clutch Lifter Cam Punch Mark Convex Mark Install the clutch lifter bearing and clutch lifter cam. Install the clutch lifter lever onto the gearshift spindle, aligning its punch mark with the notch mark on the spindle. Install the right crankcase cover (page 9-12) Clutch Lifter Lever 9-10
