                                                                               EXHAUST COMPONENTS
General Specifications*                                                                                                 Torque
                                                                                   Part             Part Bolted To
                                                                                                                        ft-lb    N-m
                               CHASSIS                               Exhaust Pipe                   Engine              20       27
Brake Type                          Hydraulic w/Brake Lever Lock                                                        48
                                                                     Spark Arrester                 Muffler                      5.5
                                    and Auxiliary Brake                                                                 in.-lb
Tire Size                           Front - 24 x 8-12                ELECTRICAL COMPONENTS
                                    Rear - 24 x 10-12
                                                                     Coil                           Frame               12       16
Tire Inflation Pressure             0.28 kg/cm (4 psi)
                                                                     Starter Motor Positive Cable   Starter Motor        8       11
                              MISCELLANY
                                                                     STEERING COMPONENTS
Gas Tank Capacity (rated)           15.1 L (4.0 U.S. gal.)
                                                                     Steering Post Bearing
Rear Drive Capacity                 250 ml (8.5 fl oz)**                                            Frame               20       27
                                                                     Housing
Front Differential Capacity         275 ml (9.3 fl oz)***
                                                                     Handlebar Cap                  Steering Post       20       27
Engine Oil Capacity                 3.3 L (3.5 U.S. qt) - Overhaul
                                    2.8 L (3.0 U.S. qt) - Change     Lower Steering Post Bearing    Steering Post       40       54
                                                                     Cap Screw
Gasoline (recommended)              87 Octane Regular Unleaded
                                                                     Tie Rod End**                  Steering Post Arm   30       41
Engine Oil (recommended)            KYMCO Synthetic
                                                                     BRAKE COMPONENTS
Differential/Rear Drive Lubricant   SAE Approved 80W-90 Hypoid       Brake Disc*                    Hub                 15       20

Drive Belt Width (minimum)          28.5 mm (1.12 in.)               Brake Hose                     Caliper             20       27

Brake Fluid                         DOT 4                            Brake Hose                     Master Cylinder     20       27

Taillight/Brakelight                12V/5W/21W                                                      Auxiliary Brake
                                                                     Brake Hose                                         20       27
                                                                                                    Cylinder
Headlight                           12V/35W (4)
                                                                     Master Cylinder (Rear)         Frame                8       11
 Specifications subject to change without notice.
 ** One inch below plug threads.                                     Master Cylinder Clamp
 *** At the plug threads.                                            Screws                         Master Cylinder     5.5       8
                                                                     (Front)
                                                                     Hydraulic Caliper              Knuckle             20       27
                                                                     CHASSIS COMPONENTS
                                                                     Footrest                       Frame (8 mm)        20       27
                                                                     Bumper                         Frame (10 mm)       35       47
                                                                     SUSPENSION COMPONENTS (Front)
                                                                     A-Arm                          Frame               35       47
                                                                     Knuckle                        Ball Joint          35       47
                                                                     Shock Absorber                 Frame               35       47
                                                                     Shock Absorber                 Upper A-Arm         35       47
                                                                     Knuckle                        A-Arm               35       47
                                                                     SUSPENSION COMPONENTS (Rear)
                                                                     Shock Absorber (Upper)         Frame               35       47
                                                                     Shock Absorber (Lower)         Lower A-Arm         35       47
                                                                     A-Arm                          Frame               35       47
                                                                     Knuckle                        A-Arm               35       47
