          19. LIGHTS/METERS/SWITCHES                         Downtown 300i ABS



 HORN

 INSPECTION
 Remove the front cover.
 Disconnect the horn connectors from the horn.

 Connect a 12 V battery to the horn terminals.
 The horn is normal if it sounds when the 12 V
 battery is connected across the horn terminals.




                                                           19-14
