          1. GENERAL INFORMATION                                            Downtown 300i ABS

                                                Before connecting a terminal, check for
  After operation, terminal caps shall be       damaged terminal cover or loose negative
  installed securely.                           terminal.




  When taking out the connector, the lock on    Check the double connector cover for
  the connector shall be released before        proper coverage and installation.
  operation.




                                                Insert the terminal completely.
  Hold the connector body when connecting       Check the terminal cover for proper
  or disconnecting it.                          coverage.
  Do not pull the connector wire.               Do not make the terminal cover opening
                                                face up.




                                                Secure wire harnesses to the frame   with
                                                their respective wire bands at        the
  Check if any connector terminal is bending,   designated locations.
  protruding or loose.                          Tighten the bands so that only        the
                                                insulated surfaces contact the       wire
                                                harnesses.




  The connector shall be inserted
  completely.                                   After clamping, check each wire to make
                                                sure it is secure.
  If the double connector has a lock, lock
  it at the correct position.
  Check if there is any loose wire.




                                                                                 1-4
