          10. CRANKCASE/CRANKSHAFT                                                AGILITY CITY50 2T

                                                   Bearing Outer Driver Handle
 Drive a new crankshaft bearing into the right
 crankcase.




                                                   Bearing Outer Driver, 37x40mm
                                                   Bearing Driver Pilot, 17mm

 Drive a new crankshaft bearing into the left
 crankcase.
                                                               Bearing Outer Driver Handle A




                                                   Bearing Outer Driver, 42x47mm
 Install the crankshaft into the left crankcase.   Pilot, 20mm
                                                   Crankcase Assembly Tool

   · Apply KYMCO ULTRA motor oil or
     molybdenum         disulfide to     the
     crankshaft bearings and connecting
     rod big end.
   · Apply grease to the lip of the oil seal
     and then install it.




                                                                                      10-6
