12. CARBURETOR VITALITY 50
Main Jet/Needle Jet Holder/Needle Jet
FLOAT CHAMBER ASSEMBLY
Install the needle jet, needle jet holder and
main jet.
Install the slow jet.
Slow Jet
Install the pilot screw.
· Be sure to record the rotating turns
when it is removed.
Pilot Screw
Float Screw Float Pin
Install the float valve, float and float pin.
Install and tighten the screw.
Float Valve
12-24
