12. CARBURETOR VITALITY 50
AUTO BYSTARTER INSPECTION
Check the auto bystarter valve and needle
for nicks, wear or damage.
If any faulty part is found, replace the auto
bystarter with a new one.
Bystarter Needle Bystarter Valve
Screws Screws
AIR CUT-OFF VALVE (A.C.V.)
REMOVAL
Remove the two screws and then remove
throttle cable holder.
Remove the two screws and the air cut-off
valve cover.
Throttle Cable Cut-off Valve Cover
Spring Cut-off Valve Cover
Remove the spring, diaphragm and O-rings.
Inspect the diaphragm and spring for wear
or damage.
O-ring Diaphragm
12-21
