1. GENERAL INFORMATION K-PIPE 125
After routing, check that the wire harnesses
are not twisted or kinked.
Wire harnesses routed along with handlebar
should not be pulled tight, have excessive
slack or interfere with adjacent or
surrounding parts in all steering positions.
Do you
understand the
When a testing device is used, make sure to instrument? Is the
understand the operating methods instrument set
thoroughly and operate according to the correctly?
operating instructions.
Be careful not to drop any parts.
When rust is found on a terminal, remove Remove Rust !
the rust with sand paper or equivalent
before connecting.
Do not bend or twist control cables.
Damaged control cables will not operate
smoothly and may stick or bind.
1-8
