          15. IGNITION SYSTEM                                                       AGILITY CITY 50

 CDI UNIT INSPECTION
 Remove the two battery cover screws.
 Disconnect the CDI coupler and remove the
 CDI unit.
 Measure the resistance between the terminals
 using the electric tester.

· Due to the semiconductor in circuit, it is
      necessary to use a specified tester for
      accurate testing. Use of an improper
      tester in an improper range may give               CDI Unit
      false readings.                                    Green         Black/ Yellow     Black/ Red
    · Use a Sanwa Electric Tester or Kowa
      Electric Tester.
    · In this table, "Needle swings then
      returns" indicates that there is a charging
      current applied to a condenser. The needle
      will then remain at "" unless the
      condenser is discharged.
                                                Green/
                                                Black


                                                              Blue / Yellow     Black / Blue   Violet/Red
                                           Violet/ Black




 Unit: K
    Probe
                    Black/ Blue/
            Black                       Green
 (-)Probe           Yellow Yellow

  Black                      1K~        10~60

 Black/
            30~80            150~400    5~15
 Yellow
  Blue/
        100~250                         40~90
 Yellow

  Green     10~30             60~200




15-3
