8. KICK STARTER/DRIVE PULLEY/
CLUTCH/DRIVEN PULLEY AGILITY RS 50 NAKED
Bearing Driver Pilot
Drive in a new needle bearing into the
driven face with the mark facing up.
Outer Driver, 24x26mm
Driven Pulley Oil Seal
CLUTCH/DRIVEN PULLEY ASSEMBLY
First install the movable driven face onto
the driven face. Then, install the guide
roller pins, O-rings and a new oil seal.
O-rings Guide Roller Pin
Install the seal collar.
Seal Collar
8-16
