          7. CYLINDER/PISTON                               DOWNTOWN 125i




 Apply engine oil to the cylinder wall, piston
 and piston ring outer surfaces.
 Pass the cam chain through the cylinder and
 install the cylinder over the piston.
 Be careful not to damage the piston rings
   and cylinder walls.


 Install the cylinder head and camshaft holder
 has installed (refer to the "CYLINDER
 HEAD" section in the chapter 6),


 Connect the water hose
 .




                                                        7-10
