11. CRANKCASE/CRANKSHAFT People GT 125i
Measure the crankshaft runout.
Service Limit: 0.1 mm (0.004 in)
Measure the crankshaft bearing play. Play
Play
Service Limits:
Axial : 0.2 mm (0.008 in)
Radial: 0.05 mm (0.002 in)
Axial
Radial
CRANKCASE ASSEMBLY
Clean off all gasket material from the
crankcase mating surfaces.
Avoid damaging the crankcase mating
surfaces.
Oil Seal
Install a new oil seal into the left crankcase.
Left Crankcase
11-5
