19. IGNITION SYSTEM MYROAD 700i IGNITION PULSE GENERATOR INSPECTION Remove the luggage box. Disconnect the ignition pulse generator connector. Measure the ignition pulse generator resistance between the Black wire and Blue wire. Standard: 10.510%K (20C/68F) IGNITION COIL REMOVAL/INSTALLATION Remove the floorboard. Disconnect the spark plug cap from the spark plug. Disconnect the ignition coil primary connectors. Remove the two nuts and the ignition coil. Installation is in the reverse order of removal. Ignition coil inspection. Standard: 3.57~4.83 Ignition Coil 10.42~14.79K 19-3
